R70-2D Specifications
PHYSICAL CHARACTERISTICS
Dimensions 66*44*24 mm
Weight 1D: 60g, 2D: 65g
Battery 1000mAh Capacity
USER INTERFACE
LED Tail indicators 3 RGB LEOs
located at the back side of the
device(programmable)
Radio status 1 Red/Blue LEOs located
on the top side of the device
Beeper Up to 70 dBA@10cm from the back of
the device beeper port
Button Scan Button x 2, Power key(programmable),
customize Button(programmable)
Scan Triggering Manual or automatic via Proximity
Sensor Technology
USER ENVIRONMENT
Operating -10~50℃（14~122°F）
Temperature
Storage -20~70℃（-4~158°F）
Temperatre
Humidity 5-95% non-condensing
1D PERFORMANCE
Scan Engine Zebra SE965
Laser Red laser(650nm)
Classification The scan engine is classified as a CDRH
Class II/IEC Class 2 device
Scanning Angle Roll Tolerance ± 35°
Pitch Tolerance ±65°
Skew Tolerance ± 40°
Print Contrast 25%
Scan Repetition Rate 104( ± 12)scan/sec (bidirectional)
Barcode Type UPC/EAN, UPC/EAN with supplementals,
Bookland EAN, UCC Coupon Extended
Code, Code 128, GS1-128, ISBT 128,
Code 39, Code 39 Full ASCII, Trioptic
Code 39, Code 32, Code 93, Code 11,
Matrix 2 of 5, Interleaved 2 of 5, Codabar
2D PERFORMANCE
Scan Engine Zebra SE2707
Illumination 1 Hyper Red 660nm LED
Aiming LED 610nm Amber LED
Focal Distance From front of engine: 7.64 inch
Field of View(FOV) 42° horizontal, 28° vertical
Scanning Angle Tilt: 360° ,Pitch: +/- 60° ,Skew: +/- 60°
Print Contrast 20%
Resolution 640 horizontal x 400 vertical pixels
LED Classification Exempt Risk Group LED product IEC/
EN 62471
Barcode Type Aztec Code, Coda bar, Codablock F,
Code 11, Code 16K, Code 128, Code
2 of 5, Code 39, Code 49, Code 93,
Data Matrix,EAN/JAN-13, EAN/JAN 8,
EAN-UCC Composite Codes, EAN-UCC
Emulation, lATA Code 2 of 5, Interleaved 2
of 5, Matrix 2 of 5,MaxiCode, MicroPDF417,
MSI, PDF417, Postal Codes (Australian Post.
British Post, Canadian Post, China Post,
Japanese Post,Korea Post, Netherlands
Post, Planet Code, Postnet), Plessey Code,
PosiCode, QR Code, RSS Expanded,
RSS limited, RSS-14,TCIF Linked Code 39,
Telepen, Trioptic Code, UPC-A, UPC E
